Teltonika Router LTE RUTXR1 Cat6 5xGbE WiFi SFP

<< Previous Next >>

Availability:

Low Stock

Delivery: 17-05-2024

Price: €627.40 627.40

quantity pcs

add to wish list

Brand: TELTONIKA

Product code/SKU: 978144

Technical data

Type	GSM 3G/4G
Colour	Aluminium
Dimensions	272 x 42.6 x 122.6 mm
Weight	1050 gram
Other features	Network: 4G (LTE) Cat 6 DL up to 300 Mbps, UL up to 50Mbps; DC-HSDPA; HSUPA; WCDMA Processor: Quad Core ARM Cortex A7 717 MHz CPU Memory: 256 MB SPI Flash, 256 MB of DDR3 RAM
Accessories included	RUTXR1 18W power supply 2 x LTE antenna (magnetic mounting, SMA plug, 3 m cable) 2 x WiFi antenna (magnetic mounting, RP-SMA plug, 1.5 m cable) Rack mounting kit 4 x pad 8 x screw SIM adapter kit Ethernet cable (1.5 m) QSG (Quick Start Guide) RMS leaflet
Model	RUTXR1
I/O ports	1 x USB 2.0 Type A
Power supply	Dual 9-50 VDC, 4-pin DC connectors
Security	Authentication: Pre-shared key, digital certificates, X.509 certificates Firewall: Pre-configured firewall rules can be enabled via WebUI, unlimited firewall configuration via CLI; DMZ; NAT; NAT-T Attack prevention: DDOS prevention (SYN flood protection, SSH attack prevention, HTTP/HTTPS attack prevention), port scan prevention (SYN-FIN, SYN-RST, X-mas, NULL flags, FIN scan attacks) VLAN: Port and tag based VLAN separation Mobile quota control: Custom data limits for both SIM cards WEB filter: Blacklist for blocking out unwanted websites, Whitelist for specifying allowed sites only Access control: Flexible access control of TCP, UDP, ICMP packets, MAC address filter WiFi security: WPA3-EAP, WPA3-SAE, WPA2-Enterprise-PEAP, WPA2-PSK, WEP; AES-CCMP, TKIP, Auto Cipher modes, client separation
Card reader	None
Data transmission	UMTS
UMTS network	1800 MHz
LTE network	1500 MHz
SIM card	Mini
Antenna	Detachable external
Environment requirements	Operating temperature: -40°C to +75°C Humidity during operation: 10% to 90% non-condensing
Operating frequency	5 GHz
Standards	802.3az
Number of antennas	Four connectors
Management, monitoring, configuration	Network features: NAT, Static/Dynamic routing, Firewall, OpenVPN, IPSec, H.232 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets Unique network features: VLAN, Mobile quota control, WEB Filter, Load Balancing, Network Backup, Auto Failover Connection monitoring: Ping Reboot, Periodic Reboot, LCP and ICMP for link inspection; WEB UI, SSH, SMS, SNMP, JSON-RPC, FOTA, RMS Authentication: Busybox shell, Lua, C, C++
Software	RutOS (OpenWrt based Linux OS)
Aero2 support	No
